Heavy Duty Cast Iron Body.
250 MM Vice S.G. Iron Body.
| Size | Jaw Opening | Jaw Width | Jaw Depth | Screw O.D. | Thread T.P.i. | Weight In Kg |
|---|---|---|---|---|---|---|
| 50 MM | 50 MM | 55 MM | 40 MM | 19 MM | 10 T.P.I. | 2.8 |
| 75 MM | 75 MM | 75 MM | 42 MM | 20.5 MM | 7 T.P.I. | 5.2 |
| 100 MM | 100 MM | 100 MM | 52 MM | 22 MM | 6 T.P.I. | 7.8 |
| 125 MM | 125 MM | 125 MM | 55 MM | 22 MM | 6 T.P.I. | 11 |
| 150 MM | 150 MM | 140 MM | 55 MM | 22 MM | 6 T.P.I. | 12 |
| 200 MM | 200 MM | 170 MM | 60 MM | 22 MM | 6 T.P.I. | 19 |
| 250 MM(SGI) | 250 MM | 210 MM | 82 MM | 25 MM | 5 T.P.I. | 22.5 |
| 300 MM(SGI) | 300 MM | 220 MM | 82 MM | 25 MM | 5 T.P.I. | 26 |
